Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-43
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 20,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
10 100% 790 195 132 100% 860 199 133
End 750 189 115 End 830 191 115
0 100% 870 211 148 100% 960 216 148
Rng 870 211 147 Rng 920 208 143
End 740 186 112 End 810 188 112
-10 100% 960 229 157 100% 1050 237 158
Rng 850 207 145 Rng 910 206 142
End 730 183 110 End 790 184 111
-20 100% 1020 245 162 100% 1130 256 163
Rng 830 202 141 Rng 900 204 141
75% 770 190 130 75% 840 193 131
End 720 180 108 End 780 180 110
-25 100% 1050 252 164 100% 1160 264 165
Rng 830 202 141 Rng 900 203 139
75% 790 193 133 75% 870 197 135
End 710 178 105 End 770 179 109
-30 100% 1090 261 166 100% 1190 275 167
Rng 830 200 139 75% 900 202 139
75% 810 198 137 Rng 890 201 138
End 710 177 104 65% 780 179 116
End 760 177 107
-40 100% 1140 277 168 100% 1260 295 169
75% 860 206 142 75% 940 212 144
Rng 820 199 138 Rng 860 195 134
65% 740 183 124 65% 820 186 127
End 700 174 103 End 750 173 105
-50 100% 1200 297 171 100% 1320 320 172
75% 900 215 145 75% 990 223 147
Rng 810 196 135 65% 860 194 133
65% 780 190 130 Rng 840 191 131
End 690 171 102 End 730 170 101
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
