LANDING DISTANCE
When the aircraft has encountered icing conditions, ap deection is limited
to a maximum deection of 20° and the approach speed is 85 KIAS.
To calculate landing distance in icing conditions, multiply the total landing
distance by 1.5, using the applicable Landing Distance chart in the main
body of this manual.
9.4-6 WEIGHT AND BALANCE
Refer to “Section 6” of this manual for current weight and balance data. Use
the following tables to determine the weight and moment/1000 for the Ice
Protection System Fluid to complete the Loading Form from “Section 6” of
this manual.
Reservoir Capacity
.............................................16.0 gallons (60.567 liters)
DTD 406B Fluid Weight
............................................. 9.2 pounds per gallon
Console Reservoir Arm
..........................................48.4 inches aft of datum
External Cargo Compartment Reservoir Arm
........... 7.1 inches aft of datum
WEIGHT AND MOMENT TABLES
NOTE: TKS SUSTAIN uid weight is 8.5 pounds per gallon.
CAUTION: Since the TKS uid reservoir is located forward of the
aircraft center of gravity, it is possible to end up outside the aft center of
gravity limit as TKS uid is used in ight. This should be considered when
performing weight and balance calculations.
Gallons Weight (LB) Moment/1000
1.0 9.2 0.45
2.0 18.4 0.89
3.0 27.6 1.34
4.0 36.8 1.78
5.0 46.0 2.23
6.0 55.2 2.67
7.0 64.4 3.12
8.0 73.6 3.56
9.0 82.8 4.01
10.0 92.0 4.45
11.0 101.2 4.90
12.0 110.4 5.21
13.0 119.6 5.34
14.0 128.8 5.79
15.0 138.0 6.68
16.0 147.2 7.12
Gallons Weight (LB) Moment/1000
1.0 9.2 0.07
2.0 18.4 0.13
3.0 27.6 0.20
4.0 36.8 0.26
5.0 46.0 0.33
6.0 55.2 0.39
7.0 64.4 0.46
8.0 73.6 0.52
9.0 82.8 0.59
10.0 92.0 0.65
11.0 101.2 0.72
12.0 110.4 0.78
13.0 119.6 0.85
14.0 128.8 0.91
15.0 138.0 0.98
16.0 147.2 1.05
Table 9.4-4 – TKS Ice Protection Fluid:
Console Reservoir
Table 9.4-5 – TKS Ice Protection Fluid:
Cargo Compartment Reservoir
