Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-44
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 21,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
0 100% 830 202 142 100% 920 207 143
End 750 186 116 End 830 189 116
-10 100% 920 219 154 100% 1010 227 154
Rng 850 205 145 Rng 910 205 142
End 740 183 113 End 810 186 112
-20 100% 980 235 160 100% 1080 245 161
Rng 840 202 142 Rng 910 205 142
75% 740 182 120 75% 810 185 123
End 730 180 110 End 790 182 111
-27 100% 1020 245 163 100% 1120 258 164
Rng 830 199 140 Rng 890 201 139
75% 770 187 129 75% 840 191 131
End 720 178 108 End 780 179 110
-30 100% 1040 250 164 100% 1150 264 165
Rng 820 198 139 Rng 890 201 139
75% 780 190 132 75% 860 195 134
End 720 177 108 End 780 178 110
-40 100% 1100 267 167 100% 1210 284 168
Rng 830 199 139 75% 910 204 140
75% 820 198 138 Rng 870 195 135
65% 710 176 113 65% 780 179 119
End 710 174 105 End 760 175 108
-50 100% 1160 287 170 100% 1270 309 171
75% 870 207 143 75% 950 215 145
Rng 810 195 136 Rng 840 190 131
65% 750 183 126 65% 830 187 129
End 700 171 104 End 750 171 104
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
