Pilot’s Operating Handbook Supplement
9.6-52
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
BALKED LANDING CLIMB GRADIENT WITH ECC
(Refer to the tables on the following page)
Conditions:
Power
........................................................................................Max Takeoff
Flaps
........................................................................................... 35° (Down)
Climb Airspeed
................................................................................74 KIAS
Winds
....................................................................................................Zero
Air Conditioning
....................................................................................... Off
Example:
Outside Air Temp
.................................................................................. 20°C
Weight
..................................................................................... 6690 pounds
Pressure Altitude
........................................................................... 6000 feet
Climb Airspeed: 74 KIAS
Climb Gradient: 484 FT/NM
NOTES:
Balked Landing Climb Gradients shown represent the gain in altitude
for the horizontal distance traveled and is expressed as Feet per
Nautical Mile.
For operation in air colder than provided in this table, use the coldest
charted data.
For operation in air warmer than provided in this table, use extreme
caution.
This chart is required for aircraft certication. However, signicantly
better performance may be achieved by climbing at the Best Rate of
Climb speeds with the aps positioned at 20° or following the Go-
Around/Balked Landing procedure outlined in “Section 4.”
Dashed entries correspond to outside air temperatures beyond the
aircraft operating limits.
NOTE: Blue numbers indicate performance with Air Conditioning
ON, black numbers indicate performance with Air Conditioning OFF.
Uncontrolled if printed
