Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-57
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 24,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 800 191 133 100% 880 198 132
End 780 188 122 End 870 195 124
-20 100% 860 206 149 100% 950 215 150
Rng 860 205 148 Rng 920 209 145
End 770 185 122 End 850 191 122
-30 100% 920 220 156 100% 1010 232 157
Rng 840 201 145 Rng 900 204 143
End 760 182 118 End 830 187 118
-33 100% 930 223 158 100% 1020 236 159
Rng 830 199 143 Rng 900 203 142
End 750 181 117 End 830 186 117
-40 100% 970 235 161 100% 1060 250 162
Rng 820 196 141 Rng 890 202 141
End 740
178 115 End 810 183 115
-50 100% 1020 254 166 100% 1130 274 167
Rng 810 193 139 Rng 870 197 138
75% 770 184 130 75% 840 191 133
End 730 175 111 End 790 178 111
CRUISE PERFORMANCE (Pressure Altitude 25,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-20 100% 820 196 140 100% 900 205 140
End 790 188 121 End 870 196 124
-30 100% 870 210 151 100% 960 221 151
Rng 840 202 146 Rng 910 206 143
End 770 185 120 End 850 192 122
-35 100% 900 216 154 100% 980 228 155
Rng 850 203 146 Rng 900 206 143
End 770 183 121 End 840 190 119
-40 100% 920 224 157 100% 1010 238 158
Rng 830 199 143 Rng 900 206 143
End 760 181 118 End 830 187 118
-50 100% 980 243 163 100% 1080 262 164
Rng 810 194 139 Rng 880 201 139
End 740
178 115 End 810 183 115
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
