Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-47
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 24,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 800 191 131 100% 880 198 130
End 780 188 121 End 870 195 122
-20 100% 860 206 148 100% 950 215 148
Rng 860 205 147 Rng 920 209 144
End 770 185 120 End 850 191 120
-30 100% 920 220 155 100% 1010 232 155
Rng 830 199 143 Rng 910 206 143
End 760 182 116 End 830 187 116
-33 100% 930 223 156 100% 1020 236 157
Rng 830 199 142 Rng 910 205 142
End 750 181 116 End 830 186 116
-40 100% 970 235 159 100% 1060 250 160
Rng 820 196 140 Rng 890
202 140
End 740 179 114 End 810 183 114
-50 100% 1020 254 164 100% 1130 274 165
Rng 810 194 138 Rng 860 195 135
75% 770 184 129 75% 840 191 132
End 730 175 110 End 790 178 111
CRUISE PERFORMANCE W/ ECC (Press. Alt. 25,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-20 100% 820 196 139 100% 900 205 139
End 790 188 121 End 870 196 123
-30 100% 870 210 149 100% 960 221 150
Rng 840 202 144 Rng 910 208 143
End 770 185 120 End 850 192 120
-35 100% 900 216 152 100% 980 228 153
Rng 840 201 143 Rng 910 206 141
End 770 183 119 End 840 190 118
-40 100% 920 224 155 100% 1010 238 156
Rng 830 199 141 Rng 900 206 141
End 760 182 116 End 830 188 116
-50 100% 980 243 161 100% 1080 262 162
Rng 820 196 139
Rng 870 199 137
End 740 178 114 End 810 183 114
Table 9.6-8 (continued) – Cruise Performance with ECC
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
