Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-45
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 22,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
0 100% 800 193 134 100% 880 198 134
End 770 188 120 End 850 192 118
-10 100% 880 210 150 100% 960 217 150
Rng 870 208 148 Rng 920 207 144
End 750 184 116 End 830 188 116
-20 100% 940 225 157 100% 1040 235 158
Rng 840 202 144 Rng 910 205 142
End 740 181 114 End 810 184 114
-29 100% 990 238 161 100% 1090 251 162
Rng 820 197 140 Rng 890 201 140
75% 740 181 122 75% 820 185 125
End 730 178 110 End 800 181 110
-30 100% 1000 240 162 100% 1100 253 163
Rng 820 197 139 Rng 890 201 139
75% 750 182 124 75% 830 187 127
End 730 178 110 End 790 180 111
-40 100% 1050 256 165 100% 1160 273 166
Rng 820 197 139 Rng 870 197 137
75% 790 190 134 75% 870 196 136
End 720 175 108 End 780 176 110
-50 100% 1110 276 168 100% 1220 297 169
75% 830 200 140 75% 920 207 142
Rng 820 195 138 Rng 860 193 134
65% 720 176 118 65% 800 180 123
End 710 172 105 End 760 173 108
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
