Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-39
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 6000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
30 100% 1170 308 158 100% 1290 311 159
Rng 980 274 143 Rng 1010 265 141
75% 880 258 134 75% 970 258 137
65% 760 238 119 65% 840 238 125
End 670 221 89 End 680 213 94
20 100% 1330 334 166 100% 1460 339 167
75% 1000 276 143 75% 1090 277 145
Rng 950 269 140 Rng 960 255 135
65% 860 253 130 65% 950 253 134
End 660 218 86 End 680 211 92
10 100% 1470 360 171 100% 1620 367 172
75% 1100 292 149 75% 1210 294 152
Rng 960 267 138 65% 1050 268 141
65% 950 267 138 Rng 970 255 135
End 650 215 84 End 670 208 92
3 100% 1560 377 174 100% 1720 387 175
75% 1170 303 153 75% 1290 306 155 65% 1010 276 142 65% 1120 277 144
Rng 940 263 135 Rng 950 251 132
End 650 214 83 End 670 207 91
0 100% 1600 386 176 100% 1760 397 177
75% 1200 308 154 75% 1320 311 156
65% 1040 280 143 65% 1140 281 146
Rng 950 264 136 Rng 940 248 130
End 650 214 83 End 670 206 90
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1670 400 177 100% 1840 414 177
75% 1250 316 156 75% 1380 320 157
65% 1090 286 145 65% 1190 288 147
Rng 980 267 136 Rng 940 246 129
End 660 212 80 End 670 204 86
-20 100% 1670 400 174 100% 1840 414 175
75% 1250 314 153 75% 1380 319 155
65% 1090 284 143 65% 1190 286 145
Rng 1020 273 138 Rng 960 248 130
End 660 211 78 End 660 202 82
-30 100% 1670 399 172 100% 1840 415 173
75% 1250 313 151 75% 1380 317 153
65% 1090 282 141 65% 1190 285 143
Rng 910 252 126 Rng 940 243 126
End 660 209 76 End 660 198 79
-40 100% 1670 399 169 100% 1840 416 171
75% 1250 311 149 75% 1380 316 151
65% 1090 280 138 65% 1190 283 142
Rng 950 256 127 Rng 920 237 122
End 660 207 72 End 650 195 77
-50 100% 1670 399 167 100% 1840 417 168
75% 1250 309 146 75% 1380 315 149
65% 1090 278 136 65% 1190 281 139
Rng 990 261 129 Rng 960 241 124
End 660 205 70 End 650 193 75
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
