Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-35
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 12,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
20 100% 1030 261 155 100% 1130 264 156
Rng 890 237 143 Rng 950 233 141
75% 770 216 127 75% 850 216 130
End 680 200 101 65% 740 198 109
End 720 196 97
10 100% 1150 282 163 100% 1260 288 164
Rng 880 233 140 75% 950 231 140
75% 860 230 138 Rng 940 229 139
65% 750 210 122 65% 820 211 126
End 680 198 99 End 710 193 96
0 100% 1260 303 168 100% 1380 312 169
75% 940 243 145 75% 1040 245 146
Rng 880 232 139 Rng 910 224 135
65% 820 220 131 65% 900 222 134
End 670 195 96 End 700 190 95
-9 100% 1350 323 172 100% 1490 335 173
75% 1010 254 149 75% 1120 258 151
Rng 890 231 138 65% 970 232 139
65% 880 230 137 Rng 910 222 134
End 660 193 94 End 690 188 95
-10 100% 1360 326 173 100% 1500 339 174
75% 1020 256 150 75% 1130 260 152
65% 890 231 138 65% 980 233 140
Rng 880 231 138 Rng 910 222 134
End 660 193 93 End 690 187 95
-20 100% 1450 347 175 100% 1600 364 176
75% 1090 267 153 75% 1200 273 155
65% 940 240 142 65% 1040 243 144
Rng 890 230 136 Rng 870 214 129
End 660 190 88 End 690 185 94
-30 100% 1530 368 177 100% 1680 389 178
75% 1150 278 155 75% 1260 285 157
65% 990 248 144 65% 1090 252 146
Rng 840 221 130 Rng 880 215 129
End 650 188 86 End 680 182 92
-40 100% 1600 389 178 100% 1760 415 179
75% 1200 288 156 75% 1320 297 158
65% 1040 255 145 65% 1140 260 148
Rng 880 225 132 Rng 870 211 126
End 650 185 87 End 670 179 90
-50 100% 1670 413 178 100% 1830 444 179
75% 1250 299 157 75% 1380 310 159
65% 1080 263 147
65% 1190 270 149
Rng 880 225 130 Rng 870 209 124
End 640 183 85 End 660 177 87
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
