Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.2-5
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
PITCH-LATCH PROPELLER
Pitch-Latch Prop
100 SERIES
9.2-1 GENERAL
DESCRIPTIVE DATA
Number of Propellers ................................................................................. 1
Propeller Manufacturer
............................................... Hartzell Propeller Inc.
Propeller Model Number
.................................... HC-E4N-3PY / D9511FSB
Number of Propeller Blades
....................................................................... 4
Propeller Diameter
...................................................................95-96 inches
Propeller Type: Constant speed, full feathering, reversible, hydraulically
actuated aluminum-bladed propeller.
Blade Angles (measured at the 30 inch radius)
Feathered Blade Angle
.............................................................. 86.1° ± 0.5°
Low Pitch Blade Angle............................................................... 17.5° ± 0.1°
Maximum Reverse Pitch
............................................................. -10° ± 0.5°
Start Lock Blade Angle
................................................................ 1.4° ± 0.2°
9.2-2 LIMITATIONS
POWERPLANT LIMITATIONS
Propeller Diameter
Maximum
.......................................................................................96 inches
Minimum
........................................................................................95 inches
Blade Angles (measured at the 30 inch radius)
Feathered Blade Angle
.............................................................. 86.1° ± 0.5°
Low Pitch Blade Angle............................................................... 17.5° ± 0.1°
Maximum Reverse Pitch
............................................................. -10° ± 0.5°
Start Lock Blade Angle
................................................................ 1.4° ± 0.2°
PROPELLER SYSTEM OPERATING LIMITATIONS
An overspeed governor test must be performed prior to the rst ight of the
day and following engine control system maintenance or adjustments.
Stabilized ground operation is prohibited between 450 and 1050 RPM. The
propeller may be operated when feathered at or below 450 RPM.
ENGINE CONTROL OPERATING LIMITATION
Flight operation with the engine power lever retarded below idle (beta
mode) is prohibited. Flight operation in beta mode may result in an engine
overspeed condition and consequent loss of engine power or loss of airplane
control. Operating in beta mode quickly produces high amounts of drag
which could result in a rapid loss of altitude or complete loss of control.
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
