Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-35
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 2000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
40 100% 1200 332 153 100% 1320 333 155
Rng 990 296 138 Rng 1020 285 136
75% 900 281 129 75% 990 281 134
65% 780 260 115 65% 860 260 122
End 660 239 80 End 670 231 90
30 100% 1370 358 161 100% 1500 361 163
75% 1020 300 140 75% 1130 300 142
Rng 1010 297 138 Rng 1050 288 137
65% 890 277 127 65% 980 277 132
End 660 238 79 End 670 229 86
20 100% 1540 388 168 100% 1700 393 169
75% 1160 320 147 75% 1270 321 149
Rng 1030 298 138 65% 1100 294 139
65% 1000 294 136 Rng 980 275 131
End 660 236 76 End 670 227 84
11 100% 1670 411 172 100% 1840 419 173
75% 1250 335 151 75% 1380 337 154
65% 1090 306 141 65% 1190 307 144
Rng 1060 302 139 Rng 1000 276 131
End 660 234 75 End 670 225 80
10 100% 1670 411 172 100% 1840 419 173
75% 1250 335 151 75% 1380 337 153
65% 1090 306 141 65% 1190 307 143
Rng 1060 301 139 Rng 1000 276 131
End 660 234 75 End 670 224 77
0 100% 1670 409 170 100% 1840 418 171
75% 1250 332 149 75% 1380 335 152
Rng 1090 305 139 65% 1190 305 142
65% 1090 304 139 Rng 1030 279 131
End 660 232 73 End 660 221 76
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1670 408 168 100% 1840 417 169
75% 1250 330 147 75% 1380 333 150
Rng 1130 309 140 65% 1190 303 140
65% 1090 302 136 Rng 980 268 126
End 660 230 70 End 660 218 74
-20 100% 1670 406 165 100% 1840 416 167
75% 1250 328 145 75% 1380 331 148 65% 1090 299 134 65% 1190 300 138
Rng 1010 287 128 Rng 980 267 124
End 660 228 70 End 660 216 72
-30 100% 1670 405 163 100% 1840 415 165
75% 1250 326 143 75% 1380 329 146 65% 1090 297 132 65% 1190 298 136
Rng 1050 292 130 Rng 1020 271 126
End 670 227 70 End 660 214 70
-40 100% 1670 404 160 100% 1840 414 162
75% 1250 324 140 75% 1380 327 144
Rng 1100 297 131 65% 1190 296 134
65% 1090 295 130 Rng 1060 274 126
End 680 225 69 End 660 212 68
-50 100% 1670 403 158 100% 1840 414 160
75% 1250 322 138 75% 1380 325 141
Rng 1150 303 131 65% 1190 294 132
65% 1090 292 127 Rng 1100 279 127
End 680 224 69 End 660 210 66
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
