Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-46
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 23,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 840 201 143 100% 920 207 143
End 770 186 120 End 850 191 118
-20 100% 900 216 153 100% 990 225 154
Rng 850 203 145 Rng 910 205 142
End 760 183 116 End 830 187 116
-30 100% 960 230 159 100% 1050 243 159
Rng 840 200 142 Rng 900 203 141
End 740 180 114 End 810 183 114
-31 100% 960 231 159 100% 1060 244 160
Rng 830 197 141 Rng 900 203 141
End 740 179 114 End 810 183 114
-40 100% 1010 245 162 100% 1110 261 163
Rng 820 196 139 Rng
880 199 138
75% 760 182 126 75% 830 188 129
End 730 176 110 End 790 179 111
-50 100% 1070 265 166 100% 1180 286 167
Rng 820 196 139 75% 880 199 138
75% 800 192 136 Rng 860 195 135
End 720 173 108 End 780 175 110
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
