Figure 9.3-1 – Parachute Operations Center of Gravity Envelope
REQUIRED PLACARDS
The following information must be displayed in the form of placards or
markings, in the approximate locations given.
1. Located on interior and exterior of the vertical sliding door:
7000
6500
6000
5500
5000
4500
4000
3500
3000
CG ENVELOPE
TRANSIENT LIMIT
CG LOCATION % MAC
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46
WEIGHT (LB)
PARACHUTE OPERATIONS CG ENVELOPE
LIFT DOOR TO OPEN
OPEN
1
AND LIFT DOOR UNTIL OPEN
SLIDE FINGERS UNDER SEAL
2
CLOSED
100-750-2603
