Kodiak 100 Series User Manual

Pilot’s Operating Handbook
2-10
DO NOT USE FOR FLIGHT OPERATIONS
Section 2
LIMITATIONS
100 SERIES
Limitations
2-6 MISCELLANEOUS INSTRUMENT MARKINGS
Miscellaneous instrument markings and their color code signicance are
provided in the table below.
Instrument
Red Line
(Minimum
Limit)
Green Band
(Normal
Operating)
Yellow
Band
(Caution
Range)
Red Line
(Maximum
Limit)
Fuel Quantity
Indicators
Empty
175 lb to
1080 lb
Empty to
175 lb
—
Generator Amps
— 0 to 240 A 240 to 300 A 300 A
Alternator Amps
— 0 to 32 A 32 to 40 A 40 A
Battery 1
Voltage
<10 V 24 V to 30 V
Low Range
10 V to 24 V
—
High Range
30 V to 33 V
Battery 2
Voltage
<10 V 24 V to 30 V
Low Range
10 V to 24 V
—
High Range
30 V to 33 V
Oxygen Supply
Pressure
Empty
400 to 2000
psig
— —
Table 2-6 – Miscellaneous Instrument Markings
2-7 WEIGHT LIMITS
Maximum Ramp Weight ................................................................... 7305 lb
Maximum Takeoff Weight
................................................................. 7255 lb
Maximum Landing Weight
................................................................ 6690 lb
Maximum Zero Fuel Weight
............................................................. 6490 lb
Minimum Flying Weight
.................................................................... 4070 lb
NOTE: Refer to “Section 6” of this manual for cabin zone loading limits
of the KODIAK 100. Refer to “Section 5” of this manual for takeoff limits
based on weight, altitude and temperature.
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
