Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-29
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 6000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
30 100% 1170 308 156 100% 1290 311 158
Rng 970 272 141 Rng 1000 264 138
75% 880 258 133 75% 970 258 136
65% 760 238 118 65% 840 238 123 End 670 221 88 End 680 214 93
20 100% 1330 334 164 100% 1460 339 165
75% 1000 276 142 75% 1090 277 144
Rng 960 269 138 65% 950 253 133
65% 860 253 129 Rng 950 253 133
End 660 218 86 End 680 211 91
10 100% 1470 360 170 100% 1620 367 170
75% 1100 292 148 75% 1210 294 150
65% 950 267
137 65% 1050 268 139
Rng 950 266 136 Rng 960 254 133
End 650 215 83 End 670 209 91
3 100% 1560 377 173 100% 1720 387 173
75% 1170 303 151 75% 1290 306 153
65% 1010 276 140 65% 1120 277 143 Rng 940 263 134 Rng 940 249 130
End 650 214 82 End 670 207 90
0 100% 1600 386 174 100% 1760 397 175
75% 1200 308 153 75% 1320 311 154
65% 1040 280 142 65% 1140 281 144 Rng 950 264 135 Rng 920 246 128
End 650 214 82 End 670 206 89
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1670 400 175 100% 1840 414 176
75% 1250 316 154 75% 1380 320 156
65% 1090 286 143 65% 1190 288 146
Rng 980 267 135 Rng 920 244 127
End 650 212 79 End 670 204 85
-20 100% 1670 400 172 100% 1840 414 173
75% 1250 314 152 75% 1380 319 154
65% 1090 284 141 65% 1190 286 144 Rng 1010 271 136 Rng 940 245 127
End 660 211 77 End 660 202 82
-30 100% 1670 399 170 100% 1840 415 171
75% 1250 313 150 75% 1380 317 152
65% 1090 282 139
65% 1190 285 142
Rng 910 252 125 Rng 950 245 126
End 660 209 75 End 660 198 78
-40 100% 1670 399 167 100% 1840 416 169
75% 1250 311 147 75% 1380 316 150 65% 1090 280 137 65% 1190 283 140 Rng 950 257 126 Rng 920 238 121
End 660 207 71 End 650 195 76
-50 100% 1670 399 165 100% 1840 417 166
75% 1250 309 145 75% 1380 315 148
65% 1090 278 134 65% 1190 281 138 Rng 980 260 127 Rng 960 242 123
End 650 204 70 End 650 193 74
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
