Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-26
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 3000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
40 100% 1160 321 151 100% 1280 322 153
Rng 990 291 139 Rng 990 276 134 75% 870 271 127 75% 960 271 132
65% 760 252 113 65% 830 251 119
End 650 234 81 End 680 227 90
30 100% 1320 346 159 100% 1450 348 160
Rng 1010 292 139 75% 1090 290 140
75% 990 289 137 Rng 1010 277 134 65% 860 267 124 65% 940 267 129 End 660 233 80 End 670 225 89
20 100% 1490 374 166 100% 1640 380 167
75% 1120 309 145 75% 1230 310 147 Rng 1000 288 136
65% 1060 284 137
65% 970 283 133 Rng 980 271 131
End 660 231 78 End 670 223 85
10 100% 1640 401 171 100% 1800 410 172
75% 1230 326 150 75% 1350 328 152 65% 1060 298 140 65% 1170 299 142 Rng 1030 292 137 Rng 970 267 129 End 660 229 76 End 670 220 83
9 100% 1650 404 171 100% 1810 412 172 75% 1240 327 151 75% 1360 330 153 65% 1070 299 140 65% 1180 300 143 Rng 1030 292 137 Rng 970 267 129 End 660 229 76 End 670 220 83
0 100% 1670 406 170 100% 1840 416 171 75% 1250 328 150 75% 1380 331 152
65% 1090 299 139 65% 1190 301 142
Rng 1060 295 138 Rng 1000 270 130
End 660 227 74 End 660 217 77
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1670 405 168 100% 1840 415 169
75% 1250 326 148 75% 1380 329 150 Rng 1100 299 138 65% 1190 299 140
65% 1090 297 137 Rng 980 264 126
End 660 225 72 End 650 214 75
-20 100% 1670 404 166 100% 1840 415 167
75% 1250 324 146 75% 1380 327 148 65% 1090 295 135 65% 1190 297 139 Rng 980 277 127 Rng 980 262 125 End 660 223 70 End 650 211 73
-30 100% 1670 403 163 100% 1840 414 165
75% 1250 322 143 75% 1380 326 146 65% 1090 293 132
65% 1190 295 137
Rng 1010 280 127 Rng 980 261 123 End 660 221 70 End 660 210 72
-40 100% 1670 402 161 100% 1840 414 163
75% 1250 320 141 75% 1380 324 144 65% 1090 291 130 65% 1190 293 135 Rng 1050 285 128 Rng 1030 265 124
End 670 220 69 End 660 208 69
-50 100% 1670 401 159 100% 1840 414 160
75% 1250 318 139 75% 1380 322 142 Rng 1100 291 129 65% 1190 290 132
65% 1090 289 128 Rng 1070 270 125 End 670 218 69 End 660 206 67
Table 9.6-8 (continued) – Cruise Performance with ECC
