Kodiak 100 Series - Weight and Balance Example Form

Pilot’s Operating Handbook
6-15
DO NOT USE FOR FLIGHT OPERATIONS
Section 6
WEIGHT AND BALANCE
100 SERIES
Weight & Bal.
WEIGHT AND BALANCE EXAMPLE FORM
Figure 6-3 – Example Visual Aid for Weight & Balance (refer to Figure 6-4)
180 LB
SEAT WEIGHTS:
TUNDRA SEATS:
Crew: 31.6 lb
Passenger: 28.1 lb
TIMBERLINE SEATS:
Crew: 33.6 lb
Passenger: 29.2 lb
180 LB
180 LB
180 LB
200 LB
Seat
Only
Seats Installed,
No Occupants
Row 5
No Seats
75 LB
Uncontrolled if printed
