Pilot’s Operating Handbook Supplement
9.6-14
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
TAKEOFF RATE OF CLIMB WITH ECC
(Refer to the tables on the following page)
Conditions:
Flaps ........................................................................................................20°
Power
............................................................................... Maximum Takeoff
Inertial Separator
...............................................................................Normal
Airspeed
...................................................................................................
Vy
Air Conditioning ....................................................................................... Off
Example:
Outside Air Temp
.................................................................................. 20°C
Weight
..................................................................................... 6000 pounds
Pressure Altitude
.....................................................................4000 FT MSL
Climb Airspeed: 86 KIAS
Rate of Climb: 1357 FT/MIN
NOTES:
Do not exceed the placarded maximum takeoff torque, ITT (790°C)
and
Ng
(101.6%) limits, or the charted max takeoff torque.
This power setting is time limited to 5 minutes.
Dashed entries correspond to outside air temperatures beyond the
aircraft operating limits.
NOTE: Blue numbers indicate performance with Air Conditioning
ON, black numbers indicate performance with Air Conditioning OFF.
NOTE: Red shaded areas represent data at temperatures greater than
the maximum approved operating OAT, but may be used for the purpose of
interpolating.
