Kodiak 100 Series User Manual

Pilot’s Operating Handbook
2-5
DO NOT USE FOR FLIGHT OPERATIONS
Section 2
LIMITATIONS
100 SERIES
Limitations
Marking
KIAS
Value or
Range
Signicance
White Arc 47 to 108
Full Flap Operating Range – The lower limit of the
white arc represents the stall speed at maximum gross
weight, with the aps extended (
Vso
). The upper limit
represents the maximum permissible speed, with the
aps fully extended.
Green Arc 68 to 182
Normal Operating Range – The lower limit of the green
arc represents the stall speed at maximum gross
weight, at the most forward C.G., with aps retracted
(
Vs
). The upper limit is the maximum operating speed.
Red Line 182
The red line indicates the maximum speed for normal
ight operations.
Table 2-3 – Standby Airspeed Indicator Markings
2-4 POWERPLANT LIMITATIONS
Number of Engines..................................................................................... 1
Engine Manufacturer
..............................................Pratt & Whitney Canada
Engine Model Number....................................................................PT6A-34
Engine Operating Limits
.........................................................See Table 2-4
Fuel Grade and Approved Fuel Additives
....See “Section 1” of this manual
Oil Grade (Specication)
................................. Oil to be used must conform
to the current revision of Pratt & Whitney Canada “Service Bulletin Number
1001.” Refer to “Section 8” of this manual for a general listing of approved
engine oils. When adding oil, service the engine with the type and brand of
oil which is currently being used in the engine.
Number of Propeller Blades
....................................................................... 4
Propeller Manufacturer
............................................... Hartzell Propeller Inc.
Propeller Model Number (Hub/Blades)
............HC-E4N-3P(Y)/D9511FS(B)
Propeller Diameter (Min-Max)
..................................................95-96 inches
Propeller Blade Angles @ 30 inch station:
Feathered
.............................................................................. 86.1° ± 0.5°
Low Pitch
............................................................................... 17.5° ± 0.1°
Reverse Pitch
.......................................................................... -10° ± 0.5°
NOTE: At lower airspeeds, the calibrated and indicated airspeeds
diverge (47 KIAS = 60 KCAS). KIAS values are approximate and may not
be accurate at the stall.
CAUTION: Do not mix different types or brands of oil.
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
