Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-30
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 7000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
30 100% 1130 296 155 100% 1240 298 157
Rng 940 263 140 Rng 970 255 138
75% 850 248 131 75% 930 248 134
65% 730 229 115 65% 810 229 120 End 670 218 92 End 690 210 93
20 100% 1270 321 163 100% 1400 325 164
75% 960 265 140 75% 1050 266 143
Rng 940 262 139 Rng 970 254 136
65% 830 243 127 65% 910 243 131
End 660 215 87 End 680 208 93
10 100% 1410 346 169 100% 1550 353 170
75% 1060 281 147 75% 1170 283 149 Rng 960 263
139 65% 1010 258 138
65% 920 257 135 Rng 930 246 132
End 660 212 86 End 680 205 91
1 100% 1530 368 173 100% 1680 378 174
75% 1140 295 151 75% 1260 298 153
65% 990 268 140 65% 1090 269 143
Rng 910 254 133 Rng 950 246 132
End 650 209 84 End 670 203 91
0 100% 1540 371 173 100% 1690 382 174
75% 1160 296 152 75% 1270 299 154
65% 1000 269 141 65% 1100 271 143 Rng 910 254 133 Rng 940 244 131
End 650 209 84 End 670 203 91
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1650 396 176 100% 1820 411 177
75% 1240 310 155 75% 1370 315 157
65% 1080 281 145 65% 1180 283 147
Rng 950 259 135 Rng 910 238 127
End 650 208 82 End 670 200 89
-20 100% 1670 399 175 100% 1840 415 176
75% 1250 311 154 75% 1380 316 156 65% 1090 281 143 65% 1190 283 146 Rng 980 262 135 Rng 920 238 127
End 650 206 80 End 670 198 84
-30 100% 1670 399 172 100% 1840 416 173
75% 1250 310 152 75% 1380 315 154
65% 1090 279 141
65% 1190 282 144
Rng 880 243 124 Rng 940 239 126
End 660 205 77 End 660 196 80
-40 100% 1670 399 170 100% 1840 417 171
75% 1250 308 149 75% 1380 314 152
65% 1090 277 139 65% 1190 280 142 Rng 910 246 125 Rng 920 234 123
End 660 203 75 End 650 192 78
-50 100% 1670 400 167 100% 1840 419 169
75% 1250 307 147 75% 1380 313 149
65% 1090 275 137 65% 1190 279 140 Rng 950 251 126 Rng 920 232 121
End 660 201 71 End 650 189 76
Table 9.6-8 (continued) – Cruise Performance with ECC
