Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-38
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 5000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
40 100% 1090 299 152 100% 1200 300 153
Rng 980 280 143 Rng 1010 271 140
75% 820 253 126 75% 900 253 130
65% 710 235 109 65% 780 234 116
End 670 228 89 End 680 219 93
30 100% 1220 321 159 100% 1340 323 161
Rng 950 275 139 75% 1010 269 139
75% 920 268 136 Rng 1000 267 138
65% 790 248 122 65% 870 248 127
End 660 225 85 End 680 217 92
20 100% 1380 348 167 100% 1520 352 168
75% 1040 287 144 75% 1140 288 147
Rng 970 276 139 65% 990 263 136
65% 900 263 132 Rng 970 261 135
End 650 221 84 End 670 214 92
10 100% 1520 374 172 100% 1680 381 173
75% 1140 303 150 75% 1260 305 152 65% 990 277 139 65% 1090 278 142
Rng 950 270 136 Rng 980 260 134
End 650 220 83 End 670 212 90
5 100% 1590 386 174 100% 1750 396 175
75% 1190 311 153 75% 1310 314 155
65% 1030 284 142 65% 1140 285 145
Rng 970 273 137 Rng 940 254 130
End 660 219 81 End 670 211 88
0 100% 1660 400 176 100% 1830 412 177
75% 1250 320 155 75% 1370 323 157
65% 1080 290 144 65% 1190 292 147
Rng 980 273 136 Rng 940 252 129
End 660 218 80 End 670 210 86
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1670 401 174 100% 1840 414 175
75% 1250 319 153 75% 1380 323 155
65% 1090 289 143 65% 1190 291 145
Rng 1020 278 138 Rng 960 254 130
End 660 217 78 End 670 208 83
-20 100% 1670 401 172 100% 1840 414 173
75% 1250 317 151 75% 1380 321 153
65% 1090 288 141 65% 1190 289 144
Rng 1050 282 139 Rng 940 249 126
End 660 215 75 End 660 204 78
-30 100% 1670 400 170 100% 1840 414 171
75% 1250 316 149 75% 1380 320 151
65% 1090 286 139 65% 1190 288 142
Rng 940 260 127 Rng 960 249 126
End 660 213 72 End 650 201 77
-40 100% 1670 399 167 100% 1840 414 169
75% 1250 314 147 75% 1380 318 149
65% 1090 284 136 65% 1190 286 140
Rng 980 265 128 Rng 960 247 124
End 660 211 70 End 650 199 75
-50 100% 1670 399 164 100% 1840 415 166
75% 1250 312 144 75% 1380 317 147
65% 1090 282 134 65% 1190 284 138
Rng 1020 271 129 Rng 990 250 124
End 660 209 69 End 660 198 72
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
