Pilot’s Operating Handbook
6-18
DO NOT USE FOR FLIGHT OPERATIONS
Section 6
WEIGHT AND BALANCE
100 SERIES
Weight & Bal.
FUEL WEIGHTS AND MOMENTS
USABLE FUEL (Jet A, Jet A-1, JP-1, JP-5, and JP-8)
WEIGHT AND MOMENT TABLE
With density of 6.7 pounds per gallon at 60°F
Gallons Weight (LB) Moment / 1000 Gallons Weight (LB) Moment / 1000
5 33 2.8 165 1105 92.2
10 67 5.6 170 1139 95.0
15 100 8.4 175 1172 97.8
20 134 11.2 180 1206 100.6
25 167 14.0 185 1239 103.4
30 201 16.8 190 1273 106.2
35 234 19.6 195 1306 109.0
40 268 22.4 200 1340 111.8
45 301 25.1 205 1373 114.6
50 335 27.9 210 1407 117.3
55 368 30.7 215 1440 120.1
60 402 33.5 220 1474 122.9
65 435 36.3 225 1507 125.7
70 469 39.1 230 1541 128.5
75 502 41.9 235 1574 131.3
80 536 44.7 240 1608 134.1
85 569 47.5 245 1641 136.9
90 603 50.3 250 1675 139.7
95 636 53.1 255 1708 142.5
100 670 55.9 260 1742 145.3
105 703 58.7 265 1775
148.1
110 737 61.5 270 1809 150.9
115 770 64.6 275 1842 153.7
120 804 67.1 280 1876 156.5
125 837 69.8 285 1909 159.3
130 871 72.6 290 1943 162.0
135 904 75.4 295 1976 164.8
140 938 78.2 300 2010 167.6
145 971 81.0 305 2043 170.4
150 1005 83.8 310 2077 173.2
155 1038 86.6 315 2110 176.0
160 1072 89.4 320 2144 178.8
Figure 6-6 – Fuel Weights and Moments
CAUTION: Visually verify the amount of fuel on board; Electric Fuel
Quantity Indicators provide advisory information only. Refer to “Section 7”
of this manual for more detail.
