Pilot’s Operating Handbook
7-71
DO NOT USE FOR FLIGHT OPERATIONS
Section 7
AIRPLANE & SYSTEMS DESCRIPTIONS
100 SERIES
Systems
INFLATABLE CREW DOOR SEALS (IF EQUIPPED)
In airplanes retrotted with the optional inatable crew door seals, both crew
doors will have an inatable seal installed along the edge of the door, as well
as a separate, feathered door seal.
Figure 7-58 – Inatable Crew Door Seal (When Installed)
NOTE: Although doors are of a standard construction, each door is
custom-t and mated to the airplane on which it is installed; doors are not
interchangeable unless they are custom modied to t.
Uncontrolled if printed
