Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-36
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 3000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
40 100% 1160 321 153 100% 1280 322 155
Rng 970 288 139 Rng 1000 278 136
75% 870 271 128 75% 960 271 133
65% 760 252 114 65% 830 251 120
End 660 234 83 End 670 227 91
30 100% 1320 346 161 100% 1450 348 162
75% 990 289 139 75% 1090 290 141
Rng 990 289 139 Rng 1020 279 136
65% 860 267 125 65% 940 267 130
End 660 233 81 End 670 225 90
20 100% 1490 374 168 100% 1640 380 169
75% 1120 309 146 75% 1230 310 149
Rng 990 288 137 65% 1060 284 138
65% 970 283 135 Rng 990 273 133
End 660 231 79 End 670 223 86
10 100% 1640 401 173 100% 1800 410 174
75% 1230 326 152 75% 1350 328 154
65% 1060 298 141 65% 1170 299 144
Rng 1020 291 138 Rng 970 267 130
End 660 229 77 End 670 220 84
9 100% 1650 404 173 100% 1810 412 174
75% 1240 327 152 75% 1360 330 154
65% 1070 299 141 65% 1180 300 144
Rng 1020 291 138 Rng 980 268 131
End 660 229 77 End 670 220 84
0 100% 1670 406 172 100% 1840 416 173
75% 1250 328 151 75% 1380 331 153
65% 1090 299 141 65% 1190 301 144
Rng 1060 295 139 Rng 1000 269 131
End 660 227 75 End 670 217 78
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1670 405 170 100% 1840 415 171
75% 1250 326 149 75% 1380 329 152
Rng 1090 298 139 65% 1190 299 142
65% 1090 297 139 Rng 960 261 126
End 660 225 73 End 660 214 76
-20 100% 1670 404 168 100% 1840 415 169
75% 1250 324 147 75% 1380 327 150
65% 1090 295 136 65% 1190 297 140
Rng 980 277 128 Rng 980 262 126
End 660 223 70 End 650 211 74
-30 100% 1670 403 165 100% 1840 414 167
75% 1250 322 145 75% 1380 326 148
65% 1090 293 134 65% 1190 295 138
Rng 1020 282 129 Rng 990 262 125
End 660 221 70 End 660 210 72
-40 100% 1670 402 163 100% 1840 414 164
75% 1250 320 143 75% 1380 324 145
65% 1090 291 132 65% 1190 293 136
Rng 1060 287 130 Rng 1020 265 125
End 670 220 69 End 660 208 70
-50 100% 1670 401 160 100% 1840 414 162
75% 1250 318 140 75% 1380 322 143
Rng 1100 290 130 65% 1190 290 134
65% 1090 289 129 Rng 1070 270 126
End 670 219 70 End 660 206 68
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
