WEIGHT AND BALANCE LOADING FORM (CONFIGURATION A)
Instructions for the form are listed on Page 6-8. Below is a visual aid and seat
weight reference. Refer to the next page for the form.
SEAT WEIGHTS:
TUNDRA SEATS:
Crew: 31.6 lb
Passenger: 28.1 lb
TIMBERLINE SEATS:
Crew: 33.6 lb
Passenger: 29.2 lb
Row 1 and Zone 1 (Crew)
Row 2 and Zone 2 (Passenger)
Row 3 and Zone 3 (Passenger)
Row 4 and Zone 4 (Passenger)
Row 5 and Zone 5 (Passenger)
Zone 6 Cargo (200 lb Max.)
Figure 6-2 – Seat Weights and Visual Aid for Weight & Balance
