Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-44
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 11,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
20 100% 1070 271 159 100% 1180 275 160
Rng 910 242 144 Rng 950 235 141
75% 800 224 131 75% 880 225 134
65% 700 206 111 65% 770 206 118
End 680 203 100 End 710 198 97
10 100% 1200 294 166 100% 1320 300 167
75% 900 239 141 75% 990 241 144
Rng 880 236 140 Rng 930 232 139
65% 780 218 127 65% 860 219 130
End 670 200 97 End 700 195 95
0 100% 1310 315 171 100% 1440 324 172
75% 980 252 148 75% 1080 255 150
Rng 890 237 140 65% 930 231 138
65% 850 229 135 Rng 920 228 136
End 660 198 96 End 690 192 94
-7 100% 1380 331 174 100% 1520 343 175
75% 1040 262 151 75% 1140 265 153
Rng 900 237 139 65% 990 239 142
65% 900 237 139 Rng 920 228 136
End 660 196 92 End 690 190 94
-10 100% 1420 339 176 100% 1560 352 176
75% 1060 266 153 75% 1170 270 155
65% 920 240 141 65% 1010 242 143
Rng 900 236 138 Rng 910 225 134
End 660 196 90 End 690 189 94
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-20 100% 1510 360 178 100% 1660 377 179
75% 1130 278 156 75% 1240 283 158 65% 980 249 144 65% 1080 252 147
Rng 880 231 135 Rng 890 221 131
End 650 193 88 End 680 187 94
-30 100% 1590 382 179 100% 1740 403 180
75% 1190 288 158 75% 1310 296 159 65% 1030 257 146 65% 1130 261 149
Rng 880 230 133 Rng 880 217 129
End 650 190 87 End 670 184 91
-40 100% 1660 403 180 100% 1820 429 181
75% 1240 298 159 75% 1370 308 160
65% 1080 265 148 65% 1180 270 150
Rng 900 233 134 Rng 870 214 126
End 640 188 86 End 670 182 88
-50 100% 1670 409 178 100% 1840 438 179
75% 1250 300 157 75% 1380 310 159
65% 1090 265 146 65% 1190 271 149
Rng 870 224 127 Rng 890 216 126
End 650 187 83 End 660 179 85
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
