CREW SEAT REMOVAL AND INSTALLATION
Crew Seat Removal:
1. Using a phillips head screw driver, locate and remove the seat stops.
2. Slide the seat AFT which will allow the AFT portion of the seat to clear
through the removal notch in the seat track.
3. After the seat has been removed, unhook the shoulder harness from the
inertia reel using the quick disconnect.
4. Update the aircraft weight and balance using the procedures dened in
“Section 6” of this manual.
