Kodiak 100 Series User Manual

Pilot’s Operating Handbook
1-8
DO NOT USE FOR FLIGHT OPERATIONS
Section 1
GENERAL
100 SERIES
General
CABIN, CARGO, AND ENTRY DIMENSIONS
Maximum Cabin Width .....................................................................54.0 IN
Maximum Cabin Height
....................................................................57.0 IN
Cabin Length (Forward Door Post to Aft Bulkhead)
..........................190 IN
Minimum Crew Door Width
.................................................................31 IN
Minimum Crew Door Height
................................................................51 IN
Maximum Crew Door Sill Height
.........................................................43 IN
BAGGAGE/CARGO COMPARTMENT DIMENSIONS
Cargo Volume (Total, Aft of Crew Seats)....................................248 CU FT
Aft Cargo Shelf Volume
................................................................38 CU FT
Minimum Cargo Door Width
...........................................................49.25 IN
Minimum Cargo Door Height..........................................................49.25 IN
Maximum Cargo Door Sill Height
........................................................38 IN
SPECIFIC LOADINGS
Wing Loading .................................................................... 30.2 LB / SQ FT
Power Loading
..................................................................... 9.67 LB / SHP
NOTE: Refer to “Section 6” of this manual for loading weight limits.
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
