Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-43
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 10,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
30 100% 980 260 151 100% 1080 262 152
Rng 930 251 146 Rng 960 242 142
75% 740 218 121 75% 810 219 125
End 680 208 101 End 710 203 96
20 100% 1110 282 160 100% 1220 285 161
Rng 890 243 141 Rng 960 240 141
75% 830 233 134 75% 920 234 137
65% 720 214 117 65% 800 214 122
End 670 205 98 End 700 200 95
10 100% 1240 305 167 100% 1370 311 168
75% 930 248 143 75% 1030 250 145
Rng 890 242 140 Rng 930 235 137
65% 810 227 129 65% 890 228 133
End 670 203 96 End 690
197 94
0 100% 1360 328 172 100% 1490 337 173
75% 1020 262 149 75% 1120 265 151
Rng 910 243 139 65% 970 240 140
65% 880 238 137 Rng 940 235 137
End 660 201 92 End 690 194 94
-5 100% 1410 339 174 100% 1550 350 175
75% 1060 269 152 75% 1170 272 153
65% 920 244 140 65% 1010 245 142
Rng 920 243 139 Rng 910 229 134
End 660 200 90 End 680 193 94
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1470 352 176 100% 1620 365 177
75% 1100 276 154 75% 1210 280 156 65% 960 250 142 65% 1050 252 145
Rng 910 242 138 Rng 890 225 131
End 660 198 88 End 680 192 94
-20 100% 1560 374 178 100% 1720 391 179
75% 1170 288 157 75% 1290 294 158 65% 1020 259 145 65% 1120 262 148
Rng 880 234 133 Rng 910 226 131
End 650 195 87 End 670 189 93
-30 100% 1640 395 179 100% 1810 417 181
75% 1230 299 158 75% 1360 306 160
65% 1070 267 147 65% 1170 271 150
Rng 900 237 134 Rng 880
220 127
End 640 193 86 End 670 187 90
-40 100% 1670 404 178 100% 1840 429 179
75% 1250 302 157 75% 1380 311 159
65% 1090 269 146 65% 1190 274 149
Rng 940 243 135 Rng 890 220 127
End 650 192 83 End 660 184 87
-50 100% 1670 405 176 100% 1840 432 177
75% 1250 301 155 75% 1380 310 157
65% 1090 268 144 65% 1190 273 147
Rng 850 224 124 Rng 900 221 126
End 650 191 81 End 660 182 82
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
