An additional jump light panel with green, white and red lights is installed on
the upper left portion of the instrument panel to facilitate communications
from the jumpmaster to the pilot. The lights are controlled by like colored
buttons located on the aft portion of the cargo door post. The signals from
the jumpmaster to the pilot are as follows:
Green Light............................................................................Turn Right 10°
White Light
............................................. Hold Heading, Speed and Altitude
Red Light
................................................................................. Turn Left 10°
VIDEO CAMERA AND MONITOR
For debrieng purposes, an external camera is mounted on the underside of
the left wing to provide video of the jump door and the parachutists exiting
the airplane.
Also located on the aft portion of the jump door post is a video monitor/
recorder. The monitor displays and records video from the externally
mounted camera. Both the video camera and monitor are protected by a
circuit breaker on the circuit breaker panel labeled VIDEO.
To operate the video camera and monitor:
• Verify the video monitor electrical connections are connected (power to
USB connector on monitor and video input to the AV IN connector on
the monitor).
• Insert a memory card by opening the LCD monitor, slide open the SD
card cover and gently push the card into the SD slot until the card
reaches the bottom of the slot.
• Turn on aircraft power.
• Turn on the video monitor by opening the LCD monitor and pressing
and holding the power button for 1 second.
• Press the record button to start recording.
• Press the record button again to stop recording.
• Turn the monitor off by pressing the power button.
Refer to the camcorder “User’s Manual” for information on playing back
recordings.
PARACHUTE STATIC LINE ATTACHMENT
The parachute static line attachment is a horizontal xture mounted to the
upper cabin structure on the right side of the cabin. The static lines are
hooked to a horizontal cable on the xture and slide aft along the cable. The
static lines will trail across the oor to the door opening and then along the
side of the airplane as parachutists exit the cabin.
9.3-8 HANDLING, SERVICE & MAINTENANCE
No change.
