Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-37
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude 4000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
40 100% 1130 310 152 100% 1240 311 154
Rng 1020 292 145 Rng 1040 280 141
75% 840 262 127 75% 930 262 132
65% 730 243 111 65% 800 243 119
End 660 231 84 End 680 223 92
30 100% 1270 333 160 100% 1400 336 161
Rng 970 282 139 75% 1050 279 140
75% 950 279 137 Rng 990 270 136
65% 830 257 124 65% 910 257 129
End 650 228 84 End 670 221 92
20 100% 1430 361 167 100% 1580 366 168
75% 1080 298 146 75% 1180 299 148
Rng 980 280 138 65% 1030 274 137
65% 930 273 134 Rng 1000 270 136
End 660 226 81 End 670 218 90
10 100% 1580 387 173 100% 1740 395 173
75% 1190 315 151 75% 1300 317 153 65% 1030 287 140 65% 1130 288 143
Rng 990 281 137 Rng 950 260 130
End 660 225 80 End 670 216 86
7 100% 1620 395 174 100% 1780 404 175
75% 1220 319 152 75% 1340 322 154
65% 1050 291 142 65% 1160 292 144
Rng 1000 283 138 Rng 950 259 129
End 660 224 79 End 670 216 86
0 100% 1670 404 174 100% 1840 415 175
75% 1250 324 153 75% 1380 327 155
65% 1090 295 143 65% 1190 297 145
Rng 1020 285 138 Rng 970 260 130
End 660 223 78 End 670 214 83
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1670 403 172 100% 1840 414 173
75% 1250 323 151 75% 1380 326 153
65% 1090 293 141 65% 1190 295 144
Rng 1060 288 139 Rng 990 263 130
End 660 221 75 End 660 211 78
-20 100% 1670 402 170 100% 1840 414 171
75% 1250 321 149 75% 1380 324 152
Rng 1090 292 139 65% 1190 293 142
65% 1090 291 139 Rng 960 255 126
End 660 219 73 End 650 207 77
-30 100% 1670 401 167 100% 1840 414 169
75% 1250 319 147 75% 1380 323 150
65% 1090 289 136 65% 1190 291 140
Rng 970 270 127 Rng 950 251 123
End 660 217 70 End 650 205 74
-40 100% 1670 400 165 100% 1840 414 166
75% 1250 317 145 75% 1380 321 147
65% 1090 287 134 65% 1190 289 138
Rng 1010 275 129 Rng 990 256 125
End 660 215 70 End 660 204 73
-50 100% 1670 400 162 100% 1840 414 164
75% 1250 315 142 75% 1380 319 145
65% 1090 285 132 65% 1190 287 136
Rng 1060 280 130 Rng 1030 261 126
End 670 214 69 End 660 202 70
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
