Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.1-3
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
S-TEC AUTOPILOT
S-Tec Autopilot
100 SERIES
S-TEC Autopilot and Yaw Damper Supplement
Table of Contents
CONTENTS PAGE
GENERAL .......................................................................................................... 9.1-7
LIMITATIONS
................................................................................................... 9.1-10
EMERGENCY PROCEDURES
.........................................................................9.1-11
AUTOPILOT MALFUNCTION
........................................................................9.1-11
YAW DAMPER MALFUNCTION
....................................................................9.1-12
ALTITUDE LOSS ............................................................................................9.1-12
SYSTEM FAILURE AND CAUTION ANNUNCIATIONS
...............................9.1-12
NORMAL PROCEDURES
............................................................................... 9.1-14
GENERAL
......................................................................................................9.1-14
AUTOPILOT PREFLIGHT TESTS
.................................................................9.1-14
IN-FLIGHT PROCEDURES ...........................................................................9.1-15
HEADING MODE
...........................................................................................9.1-15
ALTITUDE HOLD MODE
...............................................................................9.1-16
VERTICAL SPEED MODE.............................................................................9.1-16
ALTITUDE PRE-SELECT ..............................................................................9.1-17
GPS TRACKING AND GPS APPROACH .....................................................9.1-18
GPS APPROACH (WITH VERTICAL GUIDANCE) (WAAS)
.........................9.1-19
VOR TRACKING AND VOR-LOC APPROACH
............................................9.1-19
ILS INTERCEPT AND TRACKING
............................................................... 9.1-20
YAW DAMPER OPERATION
........................................................................ 9.1-21
FLIGHT DIRECTOR OPERATION ............................................................... 9.1-21
DISENGAGING THE AUTOPILOT
............................................................... 9.1-22
PERFORMANCE
............................................................................................. 9.1-22
WEIGHT AND BALANCE
............................................................................... 9.1-22
AIRPLANE & SYSTEMS DESCRIPTIONS
..................................................... 9.1-22
AUTOPILOT .................................................................................................. 9.1-22
FLIGHT DIRECTOR
..................................................................................... 9.1-23
AUTOPILOT ON - G1000 ANNUNCIATIONS
.............................................. 9.1-25
FLIGHT DIRECTOR ONLY - G1000 ANNUNCIATIONS
.............................. 9.1-25
FD/AP OFF - G1000 ANNUNCIATIONS
...................................................... 9.1-25
YAW DAMPER .............................................................................................. 9.1-2 9
HANDLING, SERVICE & MAINTENANCE
..................................................... 9.1- 30
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
