Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-33
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
CRUISE PERFORMANCE W/ ECC (Press. Alt. 10,000 FT)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
30 100% 980 260 149 100% 1080 262 151
Rng 920 249 143 Rng 960 242 141 75% 740 218 120 75% 810 219 124
End 680 208 100 End 710 203 95
20 100% 1110 282 158 100% 1220 285 159
Rng 900 244 140 Rng 960 241 140 75% 830 233 133 75% 920 234 135
65% 720 214 116 65% 800 214 121
End 670 206 97 End 700 200 95
10 100% 1240 305 165 100% 1370 311 166
75% 930 248 142 75% 1030 250 144
Rng 900 242 138 Rng 930 235 136 65% 810 227
128 65% 890 228 131
End 670 203 94 End 690 197 94
0 100% 1360 328 170 100% 1490 337 171
75% 1020 262 148 75% 1120 265 149 Rng 920 245 139 65% 970 240 138 65% 880 238 135 Rng 930 234 135
End 660 201 90 End 690 194 94
-5 100% 1410 339 172 100% 1550 350 173
75% 1060 269 150 75% 1170 272 152 Rng 920 244 138 65% 1010 245 141 65% 920 244 138 Rng 900 228 131
End 660 200 88 End 680 193 94
TEMP
°C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
-10 100% 1470 352 174 100% 1620 365 175
75% 1100 276 152 75% 1210 280 154
65% 960 250 141 65% 1050 252 143
Rng 900 240 136 Rng 900 226 130
End 660 198 88 End 680 192 93
-20 100% 1560 374 176 100% 1720 391 177
75% 1170 288 155 75% 1290 294 157
65% 1020 259 144 65% 1120 262 146 Rng 880 235 132 Rng 890 224 129 End 650 195 87 End 680 189 91
-30 100% 1640 395 178 100% 1810 417 179
75% 1230 299 157 75% 1360 306 158 65% 1070 267 146
65% 1170 271 148
Rng 910 238 133 Rng 880 220 126 End 640 193 85 End 670 187 89
-40 100% 1670 404 176 100% 1840 429 177
75% 1250 302 156 75% 1380 311 157
65% 1090 269 145 65% 1190 274 147 Rng 930 241 133 Rng 890 221 126 End 650 192 82 End 660 184 86
-50 100% 1670 405 174 100% 1840 432 175
75% 1250 301 153 75% 1380 310 155 65% 1090 268 143 65% 1190 273 145 Rng 850 224 123 Rng 900 219 124 End 650 191 80 End 660 182 81
Table 9.6-8 (continued) – Cruise Performance with ECC
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
