Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.2-3
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
PITCH-LATCH PROPELLER
Pitch-Latch Prop
100 SERIES
Hartzell Pitch–Latch Equipped Propeller
Table of Contents
CONTENTS PAGE
GENERAL
.......................................................................................................... 9.2-7
DESCRIPTIVE DATA ......................................................................................9.2-7
LIMITATIONS
..................................................................................................... 9.2-7
POWERPLANT LIMITATIONS ........................................................................ 9.2-7
PROPELLER SYSTEM OPERATING LIMITATIONS ..................................... 9.2-7
ENGINE CONTROL OPERATING LIMITATION ............................................9.2-7
POWERPLANT INSTRUMENT MARKINGS .................................................9.2-8
EMERGENCY PROCEDURES
..........................................................................9.2-8
NORMAL PROCEDURES
.................................................................................9.2-8
CHECKLIST PROCEDURES..........................................................................9.2-8
BEFORE STARTING ......................................................................................9.2-8
STARTING ......................................................................................................9.2-8
ENGINE SHUTDOWN ....................................................................................9.2-9
PERFORMANCE
...............................................................................................9.2-9
WEIGHT AND BALANCE
.................................................................................9.2-9
AIRPLANE & SYSTEMS DESCRIPTIONS
.....................................................9.2-10
PROPELLER ................................................................................................. 9.2-10
HANDLING, SERVICE & MAINTENANCE
.....................................................9.2-10
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
