Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-26
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
Table 5-9 – Takeoff Climb Gradient
7255 POUNDS WEIGHT
PRESS
ALT
FT
CLIMB
SPEED
KIAS
CLIMB GRADIENT - FT/NM
-20°C 0°C 20°C 40°C 50°C
S.L. 88 1010 958 901
607 443
549 382
2000 88 964 905
765 479 326
704 413 250
4000 87 914 855
628 363 220
574 307 161
6000 86 867
725 510 259
—
669 449 192
8000 84
772 600 397 162
—
727 548 343 104
10000 83
642 478 288 72
—
593 420 228 5
12000 82
511 358 183 - 19
—
466 307 130 - 77
6000 POUNDS WEIGHT
PRESS
ALT
FT
CLIMB
SPEED
KIAS
CLIMB GRADIENT - FT/NM
-20°C 0°C 20°C 40°C 50°C
S.L. 88 1383 1317 1247
883 682
812 607
2000 88 1326 1253
1079 727 541
1003 647 448
4000 87 1266 1193
912 588 414
846 519 341
6000 86 1212
1036 771 464
—
967 697 384
8000 84
1101 889 640 353
—
1045 825 574 283
10000 83
946 745 513 250
—
886 674 440 169
12000 82
790 601 388 143
—
733 539 324 73
5000 POUNDS WEIGHT
PRESS
ALT
FT
CLIMB
SPEED
KIAS
CLIMB GRADIENT - FT/NM
-20°C 0°C 20°C 40°C 50°C
S.L. 88 1807 1724 1636
1184 938
1097 847
2000 88 1736 1645
1427 995 767
1334 896 654
4000 87 1663 1571
1223 826 615
1141 742 527
6000 86 1598
1379 1053 680
—
1294 962 582
8000 84
1466 1203 899 550
—
1396 1125 818 465
10000 83
1279 1031 749 431
—
1205 945 660 333
12000 82
1089 859 600 305
—
1020 784 522 220
4000 POUNDS WEIGHT
PRESS
ALT
FT
CLIMB
SPEED
KIAS
CLIMB GRADIENT - FT/NM
-20°C 0°C 20°C 40°C 50°C
S.L. 88 2461 2347 2227
1624 1304
1510 1187
2000 88 2365 2240
1947 1378 1085
1823 1251 941
4000 87 2267 2142
1678 1163 893
1571 1056 782
6000 86 2182
1889 1459 979
—
1775 1341 855
8000 84
2011 1662 1265 820
—
1918 1559 1162 713
10000 83
1767 1442 1078 674
—
1670 1331 965 551
12000 82
1521 1222 892 518
—
1431 1126 793 412
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
