Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-33
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
CRUISE PERFORMANCE (Pressure Altitude SEA LEVEL)
Conditions:
Weight
..................................................................................... 7255 pounds
Engine Inlet
...................................................................................NORMAL
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
50 100% 1130 332 146 100% 1240 332 149
Rng 1020 313 139 Rng 1070 304 138
75% 850 284 122 75% 930 283 127
65% 730 264 106 65% 810 264 115
End 660 252 77 End 680 243 86
40 100% 1270 354 154 100% 1400 355 156
Rng 1040 314 139 Rng 1080 305 138
75% 960 300 131 75% 1050 300 135
65% 830 278 117 65% 910 278 124
End 660 250 76 End 680 241 83
30 100% 1460 384 162 100% 1610 387 164
75% 1100 322 141 75% 1210 322 144
Rng 1070 318 139 65% 1050 297 133
65% 950 297 128 Rng 1010 292 131
End 660 248 74 End 670 238 77
20 100% 1650 416 169 100% 1810 421 170
75% 1240 343 148 75% 1360 344 150
Rng 1100 319 139 65% 1180 315 141
65% 1070 315 137 Rng 1050 295 132
End 660 245 72 End 660 235 75
15 100% 1670 419 169 100% 1840 425 170
75% 1250 345 148 75% 1380 346 150
Rng 1120 322 140 65% 1190 317 141
65% 1090 316 137 Rng 1060 295 132
End 660 244 71 End 660 233 74
10 100% 1670 418 168 100% 1840 424 169
75% 1250 343 147 75% 1380 345 150
Rng 1130 323 140 65% 1190 316 140
65% 1090 315 136 Rng 1080 298 133
End 660 243 70 End 660 232 73
TEMP °C
2200 RPM 2000 RPM
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
PWR
TRQ
LBFT
FUEL
FLOW
PPH
TAS
KTS
0 100% 1670 416 166 100% 1840 422 167
75% 1250 341 145 75% 1380 343 148
Rng 1170 327 140 65% 1190 313 138
65% 1090 313 134 Rng 1010 285 127
End 660 241 70 End 660 230 72
-10 100% 1670 414 163 100% 1840 421 165
75% 1250 339 143 75% 1380 341 146
65% 1090 310 131 65% 1190 311 136
Rng 1050 304 129 Rng 1030 285 126
End 670 240 70 End 660 227 70
-20 100% 1670 412 161 100% 1840 420 163
75% 1250 337 141 75% 1380 338 144
65% 1090 308 129 65% 1190 309 135
Rng 1080 308 129 Rng 1060 288 127
End 680 239 69 End 660 225 67
-30 100% 1670 410 159 100% 1840 418 161
75% 1250 334 138 75% 1380 336 142
Rng 1130 313 130 65% 1190 306 132
65% 1090 305 127 Rng 1090 290 127
End 690 237 67 End 660 223 66
-40 100% 1670 409 156 100% 1840 417 158
75% 1250 332 136 75% 1380 334 140
Rng 1180 318 131 65% 1190 304 130
65% 1090 303 124 Rng 1140 296 128
End 690 236 66 End 660 220 64
-50 100% 1670 407 154 100% 1840 416 156
75% 1250 329 134 75% 1380 332 138
Rng 1230 325 132 65% 1190 301 128
65% 1090 300 121 Rng 1030 275 117
End 690 234 66 End 660 218 63
