Kodiak 100 Series User Manual

Pilot’s Operating Handbook
5-61
DO NOT USE FOR FLIGHT OPERATIONS
Section 5
PERFORMANCE
100 SERIES
Performance
Maximum Cruise Power
Press
Alt
(FT)
Climb
Fuel
(LB)
Fuel
Remaining
For Cruise
(LB)
Airspeed
(KTAS)
Fuel
Flow
(PPH)
Endurance
(Hours)
Total
Range
(NM)
Total
Specic
Range
(NM/LB)
SL 0 1907 169 420 4.5 767 0.40
2000 11 1896 170 404 4.7 798 0.42
4000 22 1885 171 387 4.9 833 0.44
6000 34 1873 172 370 5.1 871 0.46
8000 47 1860 172 354 5.3 904 0.49
10000 60 1847 172 336 5.5 946 0.51
12000 80 1827 172 321 5.7 979 0.54
14000 99 1808 171 304 5.9 1017 0.56
16000 123 1784 169 288 6.2 1047 0.59
18000 176 1731 168 273 6.3 1065 0.62
20000 230 1677 165 257 6.5 1077 0.64
Table 5-14 – Maximum Cruise Prole
Maximum Range Power
Press
Alt
(FT)
Climb
Fuel
(LB)
Fuel
Remaining
For Cruise
(LB)
Airspeed
(KTAS)
Fuel
Flow
(PPH)
Endurance
(Hours)
Total
Range
(NM)
Total
Specic
Range
(NM/LB)
SL 0 1907 140 314 6.1 850 0.45
2000 11 1896 141 299 6.3 894 0.47
4000 22 1885 141 283 6.7 939 0.50
6000 34 1873 141 268 7.0 986 0.53
8000 47 1860 140 254 7.3 1025 0.55
10000 60 1847 139 238 7.8 1079 0.58
12000 80 1827 137 225 8.1 1113 0.61
14000 99 1808 136 214 8.4 1149 0.64
16000 123 1784 137 207 8.6 1181 0.66
18000 176 1731 141 207 8.4 1179 0.68
20000 230 1677 141 202 8.3 1171 0.70
Table 5-15 – Maximum Range Prole
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
