Pilot’s Operating Handbook

5-66

DO NOT USE FOR FLIGHT OPERATIONS

Section 5

PERFORMANCE

100 SERIES

Performance

Table 5-18 – Balked Landing Climb Gradient

6690 POUNDS WEIGHT

PRESS

ALT

FT

CLIMB

SPEED

KIAS

CLIMB GRADIENT - FT/NM

-20°C 0°C 20°C 40°C 50°C

S.L. 74 1164 1090 1027

690 504

625 436

2000 74 1094 1022

864 541 367

794 465 280

4000 74 1025 959

703 403

—

641 338

6000 74

958 800 558 273

—

952 734 487 199

8000 74

832 643 415

— —

783 585 355

10000 74

675 493 279

— —

619 429 215

12000 74

524 350 152

— —

475 294 93

6000 POUNDS WEIGHT

PRESS

ALT

FT

CLIMB

SPEED

KIAS

CLIMB GRADIENT - FT/NM

-20°C 0°C 20°C 40°C 50°C

S.L. 74 1411 1327 1255

873 664

800 587

2000 74 1331 1250

1070 705 510

990 620 412

4000 74 1253 1178

887 550

—

817 478

6000 74

1176 997 724 405

—

1170 922 644 321

8000 74

1033 820 563

— —

978 755 496

10000 74

856 651 411

— —

793 579 339

12000 74

686 491 269

— —

631 428 203

5000 POUNDS WEIGHT

PRESS

ALT

FT

CLIMB

SPEED

KIAS

CLIMB GRADIENT - FT/NM

-20°C 0°C 20°C 40°C 50°C

S.L. 74 1885 1777 1686

1210 954

1121 860

2000 74 1783 1680

1455 1004 767

1356 900 647

4000 74 1684 1589

1228 815

—

1142 727

6000 74

1587 1364 1027 639

—

1579 1271 929 537

8000 74

1409 1145 830

— —

1341 1065 749

10000 74

1189 938 646

— —

1111 850 559

12000 74

980 742 474

— —

913 666 394

4000 POUNDS WEIGHT

PRESS

ALT

FT

CLIMB

SPEED

KIAS

CLIMB GRADIENT - FT/NM

-20°C 0°C 20°C 40°C 50°C

S.L. 74 2617 2467 2341

1700 1365

1582 1243

2000 74 2474 2332

2026 1431 1123

1893 1295 970

4000 74 2337 2209

1724 1185

—

1610 1072

6000 74

2206 1904 1460 959

—

2194 1781 1333 830

8000 74

1964 1614 1205

— —

1873 1509 1100

10000 74

1671 1344 968

— —

1569 1230 857

12000 74

1399 1092 750

— —

1311 994 649
