Pilot’s Operating Handbook
2-25
DO NOT USE FOR FLIGHT OPERATIONS
Section 2
LIMITATIONS
100 SERIES
Limitations
13. Located near the rewall fuel shutoff valve:
14. Located on the instrument panel near the fresh air shutoff valve:
15. Located next to the pilot and right crew shoulder harness inertia reel lever.
16. Located on the fuel tank selectors:
FIREWALL AIR
SHUTOFF
DEPRESS BUTTON
& PULL KNOB
FIREWALL FUEL
SHUTOFF
PULL OFF
SHOULDER HARNESS
INERTIA REEL
MUST BE LOCKED FOR
TAKEOFF AND LANDING
100-910-0020
UNLOCK
LOCK
SHOULDER HARNESS
INERTIA REEL
MUST BE LOCKED FOR
TAKEOFF AND LANDING
100-910-0021
UNLOCK
LOCK
Uncontrolled if printed
