Kodiak 100 Series User Manual

Pilot’s Operating Handbook
2-28
DO NOT USE FOR FLIGHT OPERATIONS
Section 2
LIMITATIONS
100 SERIES
Limitations
28. Located on the interior just aft of the cargo door, at a height greater than
the top of the passenger seat:
29. Located near the cargo door exit:
30. Baggage capacity - located at the baggage area (rear stepped area) if
equipped with Kydex interior:
TO CLOSE DOOR:
1
STOW EXTERIOR
DOOR HANDLE
PULL LOWER
DOOR SHUT
2
3
ROTATE HANDLE
TO "CLOSE"
4
PULL UPPER
DOOR SHUT
WITH HANDLE IN
"OPEN" POSITION
LATCH UPPER
HANDLE
ROTATE HANDLE
TO "CLOSE"
5 6
100-750-0021
EXIT
100-750-0011
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
