Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-6
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
3. Located on the fuel sump drain control panel:
4. Located on the ECC fuel drain access door:
5. Located on each ECC door:
6. Located on the inside of the ECC Bay 1 door:
100-910-0089
FUEL LINE DRAIN
AFT LEFT
FUEL LINE DRAIN
AFT RIGHT
VENT LINE DRAIN
LEFT
VENT LINE DRAIN
RIGHT
FUEL RESERVOIR
BLADDER DRAIN
FUEL LINE DRAIN
FORWARD PUMP BAY
PUSH TO DRAIN; PUSH AND TURN TO LOCK
FUEL DRAIN ACCESS
DRAIN DAILY
100-910-0100
100-910-0074
OPEN
CLOSE
POD BAY 1
MAX WEIGHT 290 LB
MAX FLOOR LOADING
65 LB PER SQ FT
NO SHARP EDGES
100-910-0081
NOTE: Placard 100-910-0100 supersedes 100-910-0023 (“Fuel Filter
Drain Daily”) on ECC-equipped airplanes.
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
