Kodiak 100 Series User Manual

Pilot’s Operating Handbook
2-32
DO NOT USE FOR FLIGHT OPERATIONS
Section 2
LIMITATIONS
100 SERIES
Limitations
41. Located on the oxygen bottle:
42. Located on the oxygen bottle:
43. Located on the brake uid reservoir:
WARNING: FILL WITH AVIATORS OXYGEN ONLY!
MAXIMUM FILL RATE: 200 psi / min.
MAXIMUM TANK FILL: 2000 psi.
FILL PORT: MS22066-3
KEEP OIL AND GREASE AWAY. USE ONLY EQUIPMENT
CLEANED FOR OXYGEN SERVICE AND RATED FOR
CYLINDER PRESSURE. REPLACE CAP AFTER FILLING
REFER TO FLIGHT MANUAL
DO NOT REMOVE THIS SAFETY PRODUCT LABEL
MAX
BRAKE FLUID RESERVOIR
FILL WITH MIL-H-5606 FLUID
MIN
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
