Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.6-55
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
EXTERNAL CARGO COMPARTMENT
ECC
100 SERIES
9.6-8 HANDLING, SERVICE, AND MAINTENANCE
JACKING
A series of jack adapters are provided as a tool kit for jacking the airplane.
One adapter ts into the drag brace tting on the fuselage for jacking the
nose gear. Two adapters (one for each main wheel) t onto the existing axle
assemblies for jacking the main wheels. Two additional adapters screw into
the belly of the airplane at the main landing gear carry through structure, for
jacking the airplane to remove the main landing gear. For airplanes equipped
with an external cargo compartment, two additional adapters are placed
under the outboard aft trunnion bolt and used to jack the airplane.
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
