Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.8-17
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
OVERSIZED TIRES
100 SERIES
Oversized Tires
7255 POUNDS WEIGHT
PRESS
ALT
FT
CLIMB
SPEED
KIAS
RATE OF CLIMB - FPM
-20°C 0°C 20°C 40°C 50°C
S.L. 76 1145 1112 1080
720 504
642 420
2000 76 1106 1070
920 548 335
846 466 235
4000 76 1081 1045
767 404
—
690 321
6000 76 1036
881 595 232
—
807 516 144
8000 76
941 722 435
— —
870 648 353
10000 76
765 541 253
— —
691 461 169
12000 76
595 365 86
— —
519 284 -1
6690 POUNDS WEIGHT*
PRESS
ALT
FT
CLIMB
SPEED
KIAS
RATE OF CLIMB - FPM
-20°C 0°C 20°C 40°C 50°C
S.L. 76 1334 1301 1270
883 650
798 559
2000 76 1294 1259
1100 700 471
1019 611 363
4000 76 1270 1235
937 548
—
854 457
6000 76 1226
1061 755 365
—
981 669 269
8000 76
1126 893 585
— —
1049 812 497
10000 76
940 701 393
— —
860 614 301
12000 76
760 514 216
— —
677 427 122
Table 9.108-5 – Balked Landing Rate of Climb
* The 6690 lb chart is provided for interpolation only. For landing weights of 6690 lb or less, use the tables found in the main
body of the manual along with a climb speed of 74 KIAS.
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
