Diagnostics – digital actuators
Errors are only displayed if the actuator is turned on and a test is possible for the actuator (see
the table called "Possible digital actuators"). The actuators can also be checked on the LED at
the plug, if necessary.
• Press function key
Pos: 28.132 /BA/Inf o-Center/Sensoren/ Mögliche digitale Aktor en (je nach Ausstattun g der Maschine) @ 19\mod_123842 0935128_78.doc @ 217969
Possible digital actuators (depending on how the machine is equipped)
Pos: 28.133 /BA/Inf o-Center/CC-ISOBUS- Terminal/CCI-Bi G Pack/Hauptmenüs/Hauptm enü 4 Service/Auflistu ng der möglichen digital en Altoren @ 44\mod_12761 56405140_78.doc @ 396397
No. Sensor
symbol
Description No. Sensor
symbol
Description
Y01
Main valve
Y09
Valve to open bale
channel flaps
Y02
Main valve
Y14
BigBale (error detection
is not possible)
Y03
Bale chute
Y15 MultiBale (error
detection is not
possible)
Y04
Bale chute
Y30 Knotter cleaning (error
detection is not
possible)
Y05
Bale ejector
Y31
Central lubrication
Y06
Bale ejector
M1
Knotter triggering (error
detection is not
possible)
Y07
Blade bar
Y08
Blade bar
Pos: 28.134 /BA/Inf o-Center/Sensoren/S tatusanzeige digi taler Aktoren (1,2, 3,4) @ 19\mod_1238477852587_78. doc @ 218655
State:
\\sv-kr onent1\do cudata\externalF iles\2
\xtn_1200924332322_0.wmf
Actuator on
\\sv-kr onent1\do cudata\externalF iles\2
\xtn_1200924337697_0.wmf
Actuator off
\\sv-kr onent1\do cudata\externalF iles\2
\xtn_1200924342525_0.wmf
General actuator error
\\sv- kro nen t1
\docudata\ externalFiles\2
\xtn_1200924346963_0.wmf
No power supply; fuse is probably defective
Pos: 28.135 /BA/Inf o-Center/CC-ISOBUS- Terminal/CCI-Bi G Pack/Hauptmenüs/ESC drüc ken um Menü Service 4 zu schließen b zw. zum Grundbild zuge langen @ 44\mod_127589353 0687_78.doc @ 393687
• Pressing the function key closes the called up menu
The display shows menu level 4 "Service".
• Pressing the function key
and holding it down brings up the basic screen
