Terminal menus 13
Recurring icons 13.2
Comprima V 180
Original Operating Instructions 150001053_00_en 113
Menu Sub-menu Designation
14 ISOBUS, refer to page129
14-5
TIM
Configure TIM software, refer to page129
14-9 Switch between terminals, refer to page131
15 Settings, refer to page132
15-1 Sensor test, refer to page133
15-2 Actuator test, refer to page138
15-3 Software info, refer to page140
13.2 Recurring icons
To navigate in the menu level/menus, the following icons appear again and again.
Icon Designation Explanation
Arrow pointing up Move up in order to select something.
Arrow pointing down Move down in order to select something.
Arrow pointing to the right Move to the right in order to select some-
thing.
Arrow pointing to the left Move to the left in order to select some-
thing.
Disk Save the setting.
ESC Leave menu without saving.
By pressing the key longer, the previously
viewed working screen is called up.
DEF Reset to factory setting.
