Krone Comprima V 180 - Fitting Wheel Chocks

8 Operation
8.9 Fitting wheel chocks
74
Comprima V 180
Original Operating Instructions 150001053_00_en
The parking brake(2) is located on the front side of the machine on the drawbar. The parking
brake(2) is used to secure the machine from unintentionally rolling away, .
In order to prevent the machine from rolling away, also use the wheel chocks, refer to page74.
The figure shows the parking brake applied.
Applying the parking brake(2)
 Push in the key(1) and apply the parking brake(2) until the resistance has increased
noticeably.
Releasing the parking brake(2)
 Push in the key(1) and press parking brake(2) all the way down.
Attaching safety cable of the parking brake
2
31
RP000-399
The safety cable(1) applies the parking brake(3) if the machine breaks away from the tractor
while it is driving.
 To attach the safety cable(1) to the machine, attach the safety cable(1) to the parking
brake(3). To do this, pull the safety cable(1) through the smaller loop of the safety cable(1)
and through the ring(2).
 To attach the safety cable(1) to the tractor, attach the other end of the safety cable(1) to a
suitable point at the back of the tractor.
 Ensure that the safety cable(1) cannot slip or become detached.
8.9 Fitting wheel chocks
1
2
RPG000-012
The wheel chocks(1) secure the machine against rolling away. 2wheel chocks are affixed to
the machine.
