Krone Comprima V 180 - Drive Chain of the Rollers; Checking Rear Bale Formation Conveyor

Maintenance 16
Checking rear bale formation conveyor 16.18
Comprima V 180
Original Operating Instructions 150001053_00_en 185
16.17.5 Drive chain of the rollers
1
2
X
3
RP000-474
The drive chain(1) of the rollers is located on the right side of the machine.
The dimensionX of the tensioned spring length(3) must be X=220mm.
ü The machine is shut down and safeguarded, refer to page25.
ü The right side hood is open.
 To tension the drive chain(1), use the nut(2) to set the dimension X=220mm.
INFORMATION
The drive chain is supplied with oil via the central chain lubrication system, refer to page91.
16.18 Checking rear bale formation conveyor
2
3
1
X
B
4
RP000-453
The rear bale formation conveyor should be regularly checked to prevent the rear bale
formation conveyor from being damaged or torn.
The maintenance intervals are in the maintenance table, refer to page160.
 Start to press a round bale(4) with the machine.
 When the bale diameter of the round bale(4) is X=800-1,000mm, stop the machine.
 Shut down and safeguard the machine, refer to page25.
 Check the dimensionY between the front tensioning rocker(1) and the rear tensioning
rocker(2).
Æ If the dimension Y>20mm, the setting is correct.
Æ If the dimension Y<20mm, the deflection roll(3) must be moved, refer to page186.
