8 Operation
8.13 Net and chamber film wrapping
82
Comprima V 180
Original Operating Instructions 150001053_00_en
2
1
43
6
7
8
9
5
X
RPG000-018
ü The machine is shut down and safeguarded, refer to page25.
ü You have swung the roll holder forward.
 Unwind a section of the net(7) from the net roll(1) and guide it over the deflection shaft(2)
and under the deflection roll on the cross tube(8).
 Place the net(7) over the spreading bracket(3).
 Place the net(7) under the deflection roll(4) on the retaining sheet(6).
 Guide the net(7) under the synthetic cloth(5). Ensure that the net projects over the edge of
the retaining sheet(6) by at least X=250mm.
 Spread the net(7) to a width of approximately 500mm so that the drivers of the feed roller
can pick the net up over its full width.
If the net tension is insufficient and the net is not pulled far enough to the outside of the round
bale:
 Place the net(7) under the deflection tube on the cross tube(9).
To set the feed, cutting and tying position, refer to page135.
To set the number of net layers, refer to page118.
8.13 Net and chamber film wrapping
For the "Net and chamber film wrapping" version
8.13.1 Inserting a net or film roll
To ensure that the sleeve clamp can completely catch in the sleeve of the net or film roll, the
sleeve should be made of cardboard. If a sleeve is made of plastic with grooves, the sleeve
clamp can dig into the grooves and transfer the brake force from the brake disc to the net or film
roll. Therefore, plastic sleeves without grooves are not recommended.
