Terminal menus 13
Changing value 13.5
Comprima V 180
Original Operating Instructions 150001053_00_en 115
INFORMATION
When equipped with “touch sensitive terminal”, the icons can directly be pressed.
By means of the scroll wheel
Select the desired menu by means of scroll wheel.
ð The selected menu is highlighted in colour.
To call up the menu, press the scroll wheel.
Æ The menu opens.
For version with touch sensitive terminal
By pressing the icons
To call up a menu, press the icon (e.g. ) in the display.
Æ The menu opens.
Leaving menu
Press or adjacent key.
Æ The menu closes.
13.5 Changing value
For the settings in the menus, values must be entered or changed. The values are selected
depending on used terminal (touch sensitive or not touch sensitive).
For version with touch sensitive or not touch sensitive terminal
• By means of the scroll wheel
Additionally for “Touch sensitive terminal” version
• By pressing or .
• By tipping the blue value on the display.
If a numeric value is tipped, an input mask opens. For further information on entering values
in the input mask, refer to the enclosed operating instructions of the terminal.
Examples:
By means of the scroll wheel
Choose the desired value by using the scroll wheel.
